PoissonWindow

PoissonWindow[x]

represents a Poisson window function of x.

PoissonWindow[x,α]

uses the parameter α.

Details

  • PoissonWindow, also known as the exponential window, is a window function typically used in signal processing applications where data needs to be processed in short segments.
  • Window functions have a smoothing effect by gradually tapering data values to zero at the ends of each segment.
  • PoissonWindow[x,α] is equal to  ⅇ^(-2 alpha x) 0<=x<=1/2; ⅇ^(2 alpha x) -1/2<=x<0; 0 TemplateBox[{x}, Abs]>1/2; .
  • PoissonWindow[x] is equivalent to PoissonWindow[x,3].
  • PoissonWindow automatically threads over lists.

Examples

open allclose all

Basic Examples  (3)

Shape of a 1D Poisson window:

Shape of a 2D Poisson window:

Extract the continuous function representing the Poisson window:

Parameterized Poisson window:

Scope  (6)

Evaluate numerically:

Shape of a 1D Poisson window using a specified parameter:

Variation of the shape as a function of the parameter α:

Translated and dilated Poisson window:

2D Poisson window with a circular support:

Discrete Poisson window of length 15:

Discrete 15×11 2D Poisson window:

Applications  (3)

Use the Poisson window to diminish the effect of signal partitioning when computing the spectrogram:

Use a window specification to calculate sample PowerSpectralDensity:

Calculate the spectrum:

Compare to spectral density calculated without a windowing function:

The plot shows that window smooths the spectral density:

Compare to the theoretical spectral density of the process:

Use a window specification for time series estimation:

Specify window for spectral estimator:

Properties & Relations  (3)

The area under the Poisson window:

Normalize to create a window with unit area:

Fourier transform of the Poisson window:

Power spectrum of the Poisson window:

Fourier transform of the parametrized Poisson window:

Variation of the magnitude spectrum of the Kaiser window as a function of the parameter :

Possible Issues  (1)

2D sampling of Poisson window will use a different parameter for each row of samples when passed as a symbol to Array:

Use a pure function instead:
