AutoOperatorRenderings
✖
AutoOperatorRenderings

Unsupported in Cloud

✖

is an option for cells and notebooks that specifies automatic renderings to be used for strings representing operators.

Details

  • AutoOperatorRenderings{"op1""rend1",…} specifies that the operator string opi should be automatically rendered as rendi.
  • In a typical case, the opi are multicharacter strings (such as "->") that are specified to be rendered as single-character forms (such as "").
  • Renderings specified in AutoOperatorRenderings affect display but not underlying content of expressions.
  • Auto renderings are only performed in BoxData cells.
  • Moving the text caret through an operator with an auto rendering will temporarily disable the rendering.
  • The stylesheet "Core.nb" specifies many auto renderings on some commonly used styles by default. However, auto renderings are generally disabled in documentation styles to better demonstrate exactly how to type inputs.

Examples

open allclose all

Basic Examples  (1)Summary of the most common use cases

Display the function operator "|->" as the equivalent "":

In[1]:=1
✖
https://wolfram.com/xid/0tqfm8vs03rwqe-0v78tt
Out[1]=1

Properties & Relations  (2)Properties of the function, and connections to other functions

An auto rendering does not work for a token that is not parsed to an operator:

In[1]:=1
✖
https://wolfram.com/xid/0tqfm8vs03rwqe-9i3vht
Out[1]=1

The rendering changes the appearance of an operator but not the underlying box representation:

In[1]:=1
✖
https://wolfram.com/xid/0tqfm8vs03rwqe-iomgvx
Out[1]=1

Possible Issues  (1)Common pitfalls and unexpected behavior

A poorly chosen rendering can be confusing or misleading:

In[1]:=1
✖
https://wolfram.com/xid/0tqfm8vs03rwqe-vwolqs
Out[1]=1
