MoleculeAlign
✖
MoleculeAlign

[Experimental]

✖
MoleculeAlign[ref,mol]

returns a version of mol that is aligned with reference molecule ref.

✖
MoleculeAlign[ref,mol,{r1m1,r2m2,…}]

aligns atoms in mol with index mi to the atoms in ref with index ri.

✖
MoleculeAlign[ref,mol,patt]

uses the molecule pattern patt to find an atom mapping between ref and mol.

✖
MoleculeAlign[ref,{mol1,mol2,…},patt]

aligns each of the moli with ref.

✖
MoleculeAlign[ref,mols,patt,prop]

aligns the molecules and returns the property prop of the alignment.

Details and Options

  • MoleculeAlign returns a Molecule object with the AtomCoordinates option explicitly set.
  • The atom mapping {r1m1,r2m2,…} can indicate a subset of the atoms, which will be aligned.
  • When at least three non-colinear atoms are included in the mapping, the alignment will be unique. When colinear atoms are provided, the orientation about that axis is undefined.
  • When no atom mapping is provided, ref must be present as a substructure in mol. If ref occurs multiple times, the first substructure match as found by FindMoleculeSubstructure is used.
  • When multiple molecules are aligned, the atom mapping can be provided in the form {r1{…},r2{…},…} where the right-hand sides are lists of atom indices for each molecule to be aligned.
  • Multiple molecules can be aligned either pairwise to the reference molecule with MethodAutomatic or jointly to each other and the reference molecule with Method"JointRMS".
  • If ref does not contain 3D coordinates, they are generated automatically prior to alignment.
  • The following options can be specified:
  • Weights Automaticweights for the atomic positions
    Method Automaticthe method to use
  • prop can be one of the following:
  • "Molecule"the aligned molecules
    "Transformation"the transformation functions used
    "Error"the alignment root mean squared error

Examples

open allclose all

Basic Examples  (5)Summary of the most common use cases

Align one conformation of 2,3-dihydro-4-quinolone to another:

In[1]:=1
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-i5i9mn
Out[1]=1

Align one conformation of water to another:

In[1]:=1
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-39kggb
Out[1]=1

The coordinates have been rotated and translated into alignment with the reference:

In[2]:=2
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-r01niv
Out[2]=2

Align two molecules:

In[1]:=1
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-bcw9q8
Out[1]=1

Align two molecules with an explicit atom mapping:

In[1]:=1
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-s8ci20
Out[1]=1

Align two molecules using a MoleculePattern to determine the atom mapping:

In[1]:=1
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-rwllmj
Out[1]=1

Scope  (3)Survey of the scope of standard use cases

MoleculeAlign can be used to align several conformers. Start by generating 10 conformations of adenosine with randomly oriented conformations:

In[1]:=1
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-lskvqt
Out[2]=2

Align the molecules and display them together:

In[3]:=3
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-wqrfz0
Out[3]=3

Provide a pattern to specify which parts of the conformers should be aligned:

In[4]:=4
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-ji2yny
Out[4]=4

Menthol, a monoterpene, is a substructure of jujenol, a sesquiterpene. Here are the molecules:

In[1]:=1
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-z026fr
Out[1]=1

Align jujenol to menthol:

In[2]:=2
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-yp79nz
Out[2]=2

Show the aligned result:

In[3]:=3
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-ch9m08
Out[3]=3

Align resveratrol, an endocrine disruptor, to estradiol, a hormone, using an explicitly specified atom mapping. Here are the molecules:

In[1]:=1
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-cm7dql

A utility function for visualizing the alignment:

In[2]:=2
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-ogakzx

Show the molecules together:

In[3]:=3
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-7aqmh
Out[3]=3

Align the phenol ring carbon atoms and two of the hydroxyl oxygen atoms of resveratrol to the A-ring carbon atoms and the two hydroxyl oxygen atoms of estradiol:

In[4]:=4
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-wpjte5
Out[4]=4

Show the aligned molecules:

In[5]:=5
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-ez6tr1
Out[5]=5

Compute the RMS alignment error:

In[6]:=6
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-evvyjs
Out[6]=6

Options  (2)Common values & functionality for each option

Method  (1)

When aligning multiple molecules, the default method aligns each of the moving molecules pairwise with the reference molecule. Here are three conformations of butane:

In[1]:=1
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-brrn5u
Out[1]=1

The first has the anti conformation and will serve as the reference molecule. The other two are the gauche conformations. First align with the default pairwise method:

In[2]:=2
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-er0nar
Out[2]=2

Here are the RMS deviations from the reference molecule:

In[3]:=3
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-v4tmcb
Out[3]=3

Align the molecules simultaneously by minimizing the joint sum of squared deviations:

In[4]:=4
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-twl4ih
Out[4]=4

Note that the second and third molecules are now more closely aligned to each other, as well as to the reference molecule, than in the pairwise alignment.

Here is the joint RMS deviation:

In[5]:=5
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-iy2pli
Out[5]=5

Weights  (1)

Atom weights allow specified atoms to have more influence on the alignment. Here are three molecules to demonstrate this:

In[1]:=1
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-0x4yif
Out[1]=1

Here is the alignment with the default atom weights:

In[2]:=2
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-htyedr
Out[2]=2

Increase the weight on the second atom:

In[3]:=3
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-y9c8cl
Out[3]=3

Applications  (2)Sample problems that can be solved with this function

Spironolactone is a drug that acts as an antagonist of the mineralocorticoid and androgen receptors, due to its similarity to the respective natural substrates aldosterone and testosterone. Generate molecules for spironolactone, aldosterone and testosterone:

In[1]:=1
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-ddfpxv
Out[1]=1

Align the structure of spironolactone with that of aldosterone and visualize them together:

In[2]:=2
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-duqhnp
Out[2]=2

Align the structure of spironolactone with that of testosterone and visualize them together:

In[3]:=3
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-neo1i9
Out[3]=3

Classical anticonvulsant drugs have very similar structures. Here is a list of representatives of various classes of classical anticonvulsants:

In[1]:=1
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-si4bo

Generate the molecules and find the lowest energy conformation of each:

In[2]:=2
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-d3awy7
Out[2]=2

Align the minimum energy conformations:

In[3]:=3
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-6j3j9x

Visualize the different anticonvulsants together:

In[4]:=4
✖
https://wolfram.com/xid/0tp4bzxzgfm0g6-fytqki
Out[4]=4
