LUVColor

LUVColor[l,u,v]

represents a color in the LUV color space with lightness l and color components u and v.

LUVColor[l,u,v,a]

specifies opacity a.

LUVColor["string"]

returns a color from an HTML color name etc.

LUVColor[color]

returns the LUV representation of color.

Details

  • LUVColor is a color space designed to have perceptual uniformity, i.e. equal changes in its components will be perceived by a human to have equal effects.
  • LUVColor is device independent and corresponds to the CIE 1976 color space with .
  • The parameters have the following interpretation:
  • llightness, approximate luminance
    ucolor
    vcolor
  • ColorConvert can be used to convert LUVColor to other color spaces.
  • The parameters , , and are given by , TemplateBox[{u, *}, Superscript]=13 TemplateBox[{L, *}, Superscript] (4 x/(x+15 y+3 z)-4 x_n/(x_n+15 y_n+3 z_n)), and TemplateBox[{v, *}, Superscript]=13 TemplateBox[{L, *}, Superscript] (9 y/(x+15 y+3 z)-9 y_n/(x_n+15 y_n+3 z_n)), where , , and are color parameters, , , and are white point parameters in XYZColor, and is a piecewise function that is equal to for and for .
  • LUVColor allows any real number for l, u, and v.
  • RGBColor approximately corresponds to l between 0 and 1, u between and 1.76 and v between and 0.88.
  • If no opacity has been specified, LUVColor[l,u,v] is equivalent to LUVColor[l,u,v,1].
  • LUVColor[l,u,v,a] is equivalent to {LUVColor[l,u,v],Opacity[a]}.
  • The alternative forms LUVColor[{l,u,v}] and LUVColor[{l,u,v,α}] can also be used. »
  • {LUVColor[], p1, } indicates that graphics primitives pi should be displayed in the color given.
  • The following wrappers can be used around colors:
  • ColorsNear[color,]specifies a region around color
    Directive[,color,]specifies a color in combination with other directives »
    Glow[color]specifies color independent of lighting »
    Opacity[a,color]specifies a color with an opacity a
    Style[expr,color]displays expr with the specified color »
  • For 3D surfaces, explicit LUVColor directives define surface colors; the final shading depends on lighting and contributions from specularity and glow. »

Examples

open allclose all

Basic Examples  (4)

Specify the color of graphics primitives:

Specify the color with opacity:

Specify the output color of expressions:

Specify the color of plots:

Scope  (3)

Colors in 3D  (1)

Use diffuse surface color:

Use diffuse and specular surface color:

Use glow color, setting the diffuse surface color to black:

Color Operations  (2)

Use Blend to mix two or more colors:

Use Lighter and Darker to mix with white and black, respectively:

Generalizations & Extensions  (2)

LUVColor[{l,u,v}] is equivalent to LUVColor[l,u,v]:

Use Opacity with LUVColor:

Use the opacity argument in LUVColor directly:

Properties & Relations  (1)

Blend of LUVColor directives happens in Luv parameter space:

Neat Examples  (1)

Visualizing the color space:
