SystemsModelStateFeedbackConnect

SystemsModelStateFeedbackConnect[sys,con]

connects the states of the systems model sys to the controller con and the outputs of con to the inputs of sys in feedback.

SystemsModelStateFeedbackConnect[sys,con,{s1,…},{{in1,ftype1},…}]

connects state si of sys to the i^(th) input of con and the j^(th) output of con to input inj of sys with feedback type ftypej

Details

Examples

open allclose all

Basic Examples  (3)

Determine the closed-loop model of a state-feedback system:

Compute the feedback gains to place the poles at z1 and z2 for a discrete-time system:

Determine the closed-loop model:

Verify the pole locations:

Determine the closed-loop model with a set of optimal state feedback gains:

Scope  (15)

Basic Uses  (10)

The closed-loop model of a system with state feedback:

With positive state feedback:

The state feedback gains specified as a transfer-function model:

The gains specified as a state-space model:

A affine state-space model with feedback specified in a vector:

A nonlinear state-space model with feedback specified in a vector:

Positive state feedback:

Only feedback to the first input:

Only feedback to the second input:

Connect the second state to the first input through a feedback system:

The closed-loop model of a multiple-input system:

System Types  (5)

Connect two StateSpaceModel systems:

With delays:

Using descriptor state-space models:

Input linear AffineStateSpaceModel systems:

General nonlinear NonlinearStateSpaceModel systems:

Connecting a standard linear system and an input linear system will give an affine model:

Connecting standard linear or affine system with a nonlinear system gives a nonlinear model:

Applications  (3)

The linearized inverted pendulum model is unstable:

Calculate a gain matrix to place the closed-loop poles in the left half-plane:

Find the closed-loop system:

The closed-loop response is stable:

Calculate a gain matrix to optimize a quadratic cost function of the input and the states:

Find the closed-loop system:

Calculate a gain matrix to optimize a quadratic cost function of the input and the outputs:

Find the closed-loop system:

Properties & Relations  (1)

A model where the output matrix is identity and the direct transmission matrix is zero:

SystemsModelStateFeedbackConnect and SystemsModelFeedbackConnect are equivalent:
